GDK Automatic Smart Solder Paste Printer MX PLUS from Advanced Manufacturing Services Ltd.
We’re excited to announce the latest addition to our production line the GDK Automatic Smart Solder Paste Printer MX PLUS.
This new fully automatic in-line stencil printer represents a major step forward in precision, consistency, and production efficiency for our SMT assembly process. Designed for high-quality, high-speed solder paste printing, the MX PLUS brings advanced automation and intelligent process control to the heart of PCB manufacturing.
Built for Precision and Reliability
The MX PLUS delivers exceptional solder paste printing performance using the latest SMT printing technology. Accurate solder paste deposition is critical in modern electronics manufacturing, especially with fine-pitch components and increasingly compact PCB designs.
Key capabilities of the system include:
- Fully adjustable in-line SMT solder paste printer
- 2D solder paste printing quality inspection with SPC analysis
- Fully automatic fiducial correction for highly accurate PCB and stencil alignment
- Intelligent squeegee system for optimized print consistency
- Fully programmable under-stencil cleaning system with wet, dry, and vacuum modes
- Automatic conveyor width adjustment up to 350mm
- Adjustable screen size support from 370mm × 370mm up to 737mm × 737mm (29” × 29”)
- Fast and efficient product changeover for improved production flexibility
Improving Quality and Production Efficiency
One of the standout features of the MX PLUS is its integrated 2D solder paste inspection and SPC (Statistical Process Control) analysis. This allows real-time monitoring of print quality and helps maintain consistent production standards across every PCB build.
The automatic fiducial alignment system ensures precise stencil-to-board registration, reducing defects and improving repeatability across production runs.
Its intelligent cleaning and squeegee systems also help maintain stable print quality over longer production cycles while minimizing downtime.
Supporting Future Growth
Adding the GDK MX PLUS strengthens our ability to handle increasingly complex PCB assemblies while maintaining the high standards our customers expect. The machine’s flexibility, automation, and quick changeover capabilities make it ideal for both prototype work and larger production volumes.
We’re looking forward to putting the MX PLUS to work and continuing to improve the quality, speed, and reliability of our manufacturing process.
Stay tuned for more updates from the production floor as we continue expanding our SMT capabilities.
